$1.00
Wall Mounting Rack enclosure Cabinets are designed to integrate wall mounting, which allows easy access to the network equipment.
The sealed cabinets MG series – with sides panels, back panel and front door which are all made of sealed metal, discreetly keeping your equipment.
This MG series includes SKU of various depths and also in this series are rack cabinets with additional Rack Units (heights).
| Product structure | |
| Product Series: | Wall Rack Cabinets - MG Series |
| Rack Size: | Reliable 19″ international structure |
| Rack Units: | 15U |
| Front Door: | Sealed metal door |
| Door hinges with 130 degrees operation angle | |
| Lockable door | |
| Side Panels: | Two sealed metal side panels |
| Removable side panels with plastic fasteners | |
| Lockable Side panels | |
| Back Panel: | Sealed metal panel |
| Removable back panel by screws | |
| Included: | Rear heavy duty hinge for safe wall mounting |
| wire path | |
| Can Be Added: | 1pc Fan (fan size: 120*120*25 mm) |
| Shelves | |
| Product Material | |
| Material: | SPCC - high quality cold-rolled steel |
| Thickness: | Mounting profile 2.0mm |
| Certificates | |
| CE , ROSH |
| Product Type: | 15U - MG Series - 500mm Depth | ||
| SKU: | HI-15U-500-BMG | Color: | Black |
| SKU: | HI-15U-500-MG | Color: | Gray |
| Dimensions (mm): | L 500 × W 550 × H 769 | ||
| Weight: | 19.5kg (Approximate, without additional accessories) | ||
| Maximum Weight Capacity: | 60kg | ||
| Product Type: | 15U - MG Series - 600mm Depth | ||
| SKU: | HI-15U-600-BMG | Color: | Black |
| SKU: | HI-15U-600-MG | Color: | Gray |
| Dimensions (mm): | L 600 × W 550 × H 769 | ||
| Weight: | 20.5kg (Approximate, without additional accessories) | ||
| Maximum Weight Capacity: | 60kg | ||
Note: There can be a deviation of up to 3mm in the dimensions on website, product file specifications and actual dimensions.
| Product file - 15U - MG Series - 500mm Depth - Black Color | View File | Download File |
| Product file - 15U - MG Series - 600mm Depth - Black Color | View File | Download File |
| Product file - 15U - MG Series - 500mm Depth - Gray Color | View File | Download File |
| Product file - 15U - MG Series - 600mm Depth - Gray Color | View File | Download File |
